The Pneumatic Tie Rod Cylinders 437 Series have earned their reputation as a high-performance solution designed to thrive in the diverse landscape of industrial settings. These cylinders are constructed to withstand the toughest conditions, ensuring longevity and dependability. When it comes to heavy-duty applications that demand unwavering precision and reliability, the 437 Series cylinders are the go-to choice, consistently delivering the pneumatic force required to keep operations running smoothly.

Shop Help Me

Key features and benefits of the Pneumatic Tie Rod Cylinders 437 Series

Key Features

The AVENTICS Series 437 offers a wide range of mountings and sensors, allowing for flexibility and adaptability in various industrial applications. This feature makes it easy to integrate these cylinders into different systems and configurations, enhancing their versatility and usability.

Key Features

These cylinders come equipped for magnetic position detectors, which enable precise and reliable monitoring of the cylinder's position. This feature is essential for applications where precise positioning and control are critical, ensuring accuracy and efficiency in operations.

Key Features

The 437 Series cylinders can handle both lubricated and unlubricated air, providing compatibility with different air systems and maintenance preferences. Additionally, they are designed to operate effectively within an ambient temperature range of -10°C to 70°C, making them suitable for a wide range of environmental conditions and industrial settings.

We provide comprehensive technical drawing services for pneumatic cylinders, with skilled artists ready to create the drawings you require. Simply let us know your specifications and needs.


Functional Principle:	Double-acting
Ambient Temperature Range:	-10°C to 70°C
Maximum Working Pressure:	10 Bar
Medium:	Compressed Air
Standards:	CNOMO 06-07-02 to 06-07-15
Max Speed Rate:	2 m/s

Pneumatic Tie Rod Cylinders 437 Series are commonly used for linear motion applications in various industries to convert compressed air pressure into mechanical force, facilitating tasks like lifting, pushing, or pulling heavy loads.

The 437 Series features tie rods that secure the cylinder's end caps, making it highly durable and suitable for heavy-duty applications. This design allows for easy maintenance and repair.

The 437 Series typically comes in a range of standard bore sizes, with options to fit specific application requirements. Common sizes include 1.5 inches to 4 inches in diameter.

Pneumatic Tie Rod Cylinders 437 Series are often made from high-quality materials such as aluminum or steel, ensuring resistance to corrosion and wear, and enhancing their longevity.

Yes, many manufacturers offer customisable stroke lengths for the 437 Series cylinders, allowing you to tailor them to your specific application needs.

These cylinders typically come with various mounting options, such as flange, trunnion, or clevis mounts, making it easier to integrate them into your machinery.

Yes, various accessories like rod boots, cushions, and position sensors are often available to enhance the functionality and performance of these cylinders.

In this guide, we delve into the world of tie rod pneumatic cylinders, essential components in industrial automation. Click the following link to learn more today.

Learn More

Manuals, Datasheets and Certificates

Please feel free to request information and advice using the form below or call us on 0151 547 1221

Pneumatic Tie Rod Cylinders 437 Series

Pneumatic Tie Rod Cylinders 437 Series

Key Features

Key Features

Key Features

Key Features

Need More Dimensions?
